MEB3200 JUKI Eyelet Button Holing Machine (Keyhole)
(**Please call or email for pricing and availability.)
MEB-3200 SERIES
Computer-controlled, Eyelet Buttonholing Machine
This series is best suited for Lightweight to Medium fabric application.
The electronically controlled machine permits the selection and setting of various eyelet shapes. With its new technology called "active tension" (electronic thread tension mechanism), the machine is capable of duplicating the same sewing conditions with ease.
| Model name | MEB-3200SS | MEB-3200RS |
|---|---|---|
| Thread trimming style | Longer remaining thread | |
| Sewing speed | 400～2,200sti/min (100sti/min step) | |
| Sewing length | 10～38mm (with thread trimmer) 10～50mm (in case looper thread trimming device is removed)*1 |
|
| Needle throwing width | 2～3.2mm *2 | |
| Taper bar length | 0mm, 3～15mm | |
| Needle | DO×558 (Nm100) Nm90～Nm110 |
|
*1 When the sewing length of 38~50mm without thread trimmer is selected, the work clamp can be provided by placing special order.
*2 By selecting the left looper and left spreader, the range of stitch bite can be changed to 2.6~4.0mm from 2.0~3.2mm (TS model is excluded)
